Khoom Parameters
Alloy Carbon Steel Seamless Pipes
Khoom siv, Specification, Ntsiab nta
EN-10084 16MnCr5 alloy carbon steel seamless kav yog ib hom steel kav tsim thiab tsim kom tau raws li cov specifications teev nyob rau hauv EN-10084 qauv. Cov kav dej no paub txog lawv lub zog tshwj xeeb, ua haujlwm ntev, thiab tsis kam hnav thiab tsim kua muag, ua rau lawv haum rau ntau yam kev lag luam uas yuav tsum muaj kev ua haujlwm siab. Cov yam ntxwv tseem ceeb ntawm EN-10084 16MnCr5 alloy carbon steel seamless kav suav nrog:
Siab zog: Lub alloy muaj pes tsawg leeg ntawm 16MnCr5 steel txhim khu nws lub zog, tso cai rau nws tiv taus hnyav loads thiab pressures.
Zoo Toughness: Cov kav dej no muaj qhov zoo toughness, ua rau lawv tiv taus tawg thiab deformation txawm nyob rau hauv huab cua.
Zoo heev hnav tsis kam: Vim muaj cov ntsiab lus alloying xws li chromium, cov kav dej no muaj kev tiv thaiv zoo heev rau hnav thiab puas, ua rau lawv lub neej ua haujlwm ntev.
Seamless Kev Tsim Kho: EN-10084 16MnCr5 cov kav dej yog tsim los siv cov txheej txheem kev tsim kho seamless, kom ntseeg tau tias muaj kev sib haum xeeb hauv cov phab ntsa tuab thiab txhim kho cov qauv kev ntseeg siab.
Chemical Composition (Table Presentation)
| Element | Kev sib xyaw (%) |
| Cov pa roj carbon (C) | 0.14 - 0.19 |
| Silicon (Si) | 0.40 max |
| Manganese (Mn) | 1.00 - 1.30 |
| Phosphorus (P) | 0.025 max |
| Sulfur (S) | 0.035 max |
| Chromium (Cr) | 0.80 - 1.10 |
Mechanical Properties (Table Presentation)
| Khoom | Tus nqi |
| Tensile zog | 800 - 1000 MPa |
| Yield zog | 600 - 800 MPa |
| Elongation | 12 - 16% |
| Hardness (HB) | 170 - 220 HB |
Physical Properties (Table Presentation)
| Khoom | Tus nqi |
| Qhov ntom | 7.85 g / cm³ |
| Melting Point | 1420 - 1460 degree |
| Thermal conductivity | 42.7 W/m·K |
| Tshwj xeeb kub | 0.473 J/g·K |
| Hluav taws xob conductivity | 1.51e6 S/m |
Process Performance (Table Presentation)
| Performance Parameter | Tus nqi |
| Weldability | Zoo |
| Machineability | Nruab nrab |
| Formability | Zoo heev |
| Kev kho cua sov | Hardenable |
| Kev kho saum npoo | Plating, Txheej |
Steel Qib, Daim Ntawv Thov
Qib steel: EN -10084 16MnCr5
Daim ntawv thov: EN-10084 16MnCr5 alloy carbon steel seamless kav pom dav siv nyob rau hauv ntau yam lag luam suav nrog:
Automotive Kev Lag Luam: Siv rau hauv kev tsim cov iav, ncej, thiab lwm yam khoom siv tsheb vim lawv lub zog siab thiab hnav tsis kam.
Machinery thiab Equipment: Tsim nyog rau cov khoom siv los ntawm cov khoom hnyav thiab cov khoom siv abrasive.
Kev tsim kho: Siv nyob rau hauv kev tsim kho tshuab thiab cov cuab yeej siv qhov chaw durability thiab toughness yog qhov tseem ceeb.
Mining thiab Quarrying: Siv nyob rau hauv fabrication ntawm cov khoom siv mining thiab machinery Cheebtsam.
Roj thiab Roj: Siv rau hauv cov kav dej thiab cov khoom siv drilling vim lawv muaj peev xwm tiv taus qhov kub siab thiab corrosive ib puag ncig.
Cov qhab nia xaiv tau
Thaum EN-10084 16MnCr5 alloy carbon steel seamless kav muaj kev ua tau zoo, muaj lwm qib muaj rau cov ntawv thov tshwj xeeb. Qee cov qhab nia ua tau muaj xws li:
20MnCr5: Muab cov hardenability ntau dua thiab hnav tsis kam piv rau 16MnCr5, haum rau cov ntawv thov uas xav tau cov khoom siv zoo tshaj plaws.
42CrMo4: Muab kev txhim kho lub zog thiab lub zog, zoo tagnrho rau cov khoom hnyav- cov tshuab ua haujlwm thiab cov cuab yeej siv rau kev ntxhov siab thiab kev cuam tshuam.
TIAB SA 4140: Muaj ntau yam alloy steel qib nrog zoo machinability thiab siab tensile lub zog, haum rau ntau yam kev siv xws li automotive thiab aerospace Cheebtsam.
Kev xaiv qib zoo yog nyob ntawm cov kev cai tshwj xeeb ntawm daim ntawv thov, xav txog yam xws li cov khoom siv kho tshuab, kev ua haujlwm, thiab tus nqi- ua tau zoo.
EN-10084 16MnCr5 alloy carbon steel seamless kav dej muaj kev txhim khu kev qha rau kev lag luam xav tau siab- cov ntaub ntawv ua tau zoo nrog lub zog zoo, tawv, thiab hnav tsis kam. Nrog lawv cov seamless kev tsim kho thiab ntau yam khoom, cov kav dej no pab txhawb rau kev ua tau zoo thiab ua haujlwm ntev ntawm ntau yam kev lag luam.
