Khoom Parameters
EN10216-1 Seamless Kub Rolled Thiab Cold Drawn Steel Tube Thiab Yeeb Nkab
saib tag
EN10216-1 yog tus qauv European rau seamless steel raj rau lub hom phiaj siab, npog tsis yog- cov hlau alloy steel nrog cov khoom tshwj xeeb hauv chav tsev kub. Tus txheej txheem qhia txog cov txheej txheem kev xa khoom rau kub- dov thiab txias- kos cov raj steel. EN10216-1 seamless steel tubes yog hollow raj plhaub tsim los ntawm kos ib lub steel billet los ntawm ib tug perforated bar, tsis muaj welds los yog seams. Cov raj hlau no tsim nyog rau kev siv qhov kub thiab txias, xws li cov kav dej boiler, fais fab nroj tsuag, thiab cov nroj tsuag petrochemical.
Qhov Loj
OD: 10.2-711mm
WT: 1-100 hli
L: max 12000mm
Ntsiab nta
Cov qauv seamless ua kom zoo ib yam thiab muaj zog thiab tuaj yeem tiv taus siab dua.
Muaj ob txoj hauv kev, kub dov, thiab kos duab txias, uas tuaj yeem xaiv raws li qhov xav tau tiag tiag ntawm daim ntawv thov.
Tshuaj muaj pes tsawg leeg
| Element | Feem pua (%) |
| C (Carbon) | 0.16 max |
| Si (Silicon) | 0.35 max |
| Manganese (Mn) | 1.20 max |
| P (phosphorus) | 0.025 max |
| S (Sulfur) | 0.020 max |
Mechanical Properties
| Khoom | Tus nqi |
| Tensile zog | 410-530 MPa |
| Yield zog | 255 MPa min |
| Elongation | 21% min |
| Impact Test | -20 degree, 27J min |
Lub cev muaj zog
| Khoom | Tus nqi |
| Qhov ntom | 7.85 g / cm³ |
| Melting Point | 1420-1460 degree |
| Thermal conductivity | 50 W/m·K |
| Tshwj xeeb kub | 490 J/Kg |
Txheej Txheem Kev Ua Haujlwm
| Kev ua tau zoo | Specification |
| Kub Rolled | Txoj kab uas hla: 21.3-660mm; Thickness: 2.0-30 hli |
| Txias Drawn | Txoj kab uas hla: 10-108mm; Thickness: 1.5-10mm |
Qib Steel
Cov qib steel npog los ntawm EN10216-1 suav nrog:
P195TR1/P195TR2
P235TR1/P235TR2
P265TR1/P265TR2
Daim ntawv thov
Boilers, Kub exchangers
Petrochemical kev lag luam
Roj thiab roj tsheb thauj mus los
Kev ua tshuaj lom neeg
Cov qhab nia xaiv tau
Lwm cov qhab nia uas tuaj yeem txiav txim siab raws li cov cai tshwj xeeb thiab cov ntawv thov suav nrog:
ASTM A106/A106M
ASTM A53 / A53M / ASTM A53M / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / A53M / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53 / ASTM A53) thiab ASTM A53 / A53M
TIAB SA 17175
Cov qhab nia hloov pauv no tuaj yeem muab cov khoom zoo sib xws lossis txhim kho nyob ntawm seb qhov kev siv tau npaj tseg. Nco ntsoov sab laj nrog cov kws tsim khoom siv los txiav txim siab qib uas tsim nyog rau koj daim ntawv thov.
