Khoom Description
Peb Qhov Zoo
1. Zoo heev hnav thiab corrosion kuj
- Cov chromium thiab molybdenum nyob rau hauv peb 38CrMoAl alloy tubes txhim khu lub hardness thiab txo cov khoom poob vim kev sib txhuam, ua rau lawv tsim nyog rau cov khoom raug rov qab kev nyuaj siab los yog mechanical hnav.
- Cov raj tau txais kev sim tshuaj lom neeg muaj pes tsawg leeg los xyuas kom meej tias cov ntsiab lus chromium thiab molybdenum ua tau raws li cov qauv kev qhia tshwj xeeb lossis cov neeg siv khoom xav tau, lav lub sijhawm ntev - lub sijhawm ua haujlwm nyob rau hauv siab - qhov kub thiab txias ib puag ncig.
2. Superior Surface Quality
- Peb 38CrMoAl alloy tubes yog tsim los siv cov txheej txheem kos duab txias, ua rau muaj qhov siab ntawm qhov smoothness, cov phab ntsa tuab, thiab tsis muaj nplai.
- Cov raj tau txais kev tshuaj xyuas qhov muag, kuaj qhov roughness ntawm qhov chaw, thiab tsis yog -kev kuaj xyuas kom ntseeg tau tias qhov chaw tsis muaj khawb, dents, lossis nplai.
3. Siab Dimensional raug
- Peb cov raj yog tsim los siv cov txheej txheem kub hnyiab thiab txias txheej txheem, kom ntseeg tau tias cov txheej txheem sab nraud, phab ntsa tuab, thiab kev ua siab ntev ua tau raws li cov neeg siv khoom xav tau.
- Cov hlab ntsha raug tswj xyuas los yog quenching thiab tempering kev kho mob kom tshem tawm cov kev ntxhov siab uas tshwm sim thaum lub sij hawm tsim, tiv thaiv deformation, ovality, los yog khoov thaum ua thiab tom qab kev kho mob.
4. Zoo heev mechanical zog
- Peb cov hlau alloy muaj lub zog tensile siab, lub zog tawm los, thiab lub zog, muaj peev xwm txhawb nqa hnyav - lub luag haujlwm tsav shafts, crankshafts, gears, thiab piston rods yam tsis muaj deformation lossis puas.
- Cov raj tau raug kuaj xyuas cov cuab yeej cuab tam nruj thiab tsis yog -kev sim ua kom puas tsuaj kom ntseeg tau tias lub raj zoo ua tau raws li ASTM, DIN, EN, thiab lwm yam kev qhia tshwj xeeb.
thaj chaw thov
- Automotive Kev Lag Luam: Tsav shafts, kis ncej, thiab iav qhov chaw.
- Cov cuab yeej siv tshuab: Hydraulic lub tog raj kheej raj, lub tes tsho, thiab spindles rau cov khoom hnyav; coj tus pins, bushings, thiab pwm puag rau txhaj tshuaj molding tshuab.
- Lub zog thiab lub zog kev lag luam: Turbine shafts thiab siab - ceev spindles, valve stems, thiab twj tso kua mis Cheebtsam.
- Metallurgical thiab Mining khoom: Drill bushings, laum rods, thiab couplings.
- Tool thiab Tuag Kev Lag Luam: Moulding tuag, mandrels, thiab ejector tes tsho.
Tshuaj muaj pes tsawg leeg
| Element | C | Si | Mn | Cr | Mo | Al | Ni | S & P (max) |
| Kev sib xyaw (%) | 0.35–0.42 | 0.17–0.37 | 0.40–0.70 | 1.30–1.60 | 0.15–0.25 | 0.70–1.10 | Tsawg dua los yog sib npaug li 0.30 | Tsawg dua lossis sib npaug li 0.025 |
Mechanical Properties
Hauv qab no38CrMoAl Alloy Tubesmuaj mechanical zogtom qab quenching thiab tempering. Tom qab nitriding, lub hardness ntawm lub nto mus txog 900-1100 HV, nrog zoo heev hnav tsis kam.
| Khoom | Tensile zog | Yield zog | Elongation | Kev txo qis ntawm cheeb tsam | Impact Toughness | Hardness |
| Tus nqi | Ntau dua lossis sib npaug li 980 MPa | Ntau dua lossis sib npaug li 835 MPa | Ntau dua lossis sib npaug li 10% | Ntau dua lossis sib npaug li 40% | Ntau dua lossis sib npaug rau 63 J | Tsawg dua lossis sib npaug rau 269 HRB |
Cov qhab nia xaiv tau
- DIN/EN 31CrMoV9, 41CrAlMo7: Muab cov khoom zoo sib xws hardenability thiab nitriding, dav siv nyob rau hauv European machinery thiab automotive qhov chaw.
- ISO (International) 38CrAlMo6: Tus qauv nitriding steel qib nrog ze li cov tshuaj lom neeg zoo tib yam, haum rau kev siv thoob ntiaj teb.
- JIS (Nyiv) SACM645: Japanese nitriding steel nrog zoo heev nto hardness thiab hnav tsis kam, siv nyob rau hauv pwm thiab precision machinery.
- AISI/SAE (US) 9840: Qhov ze tshaj plaws hauv Teb Chaws Asmeskas sib npaug, siv qhov twg yuav tsum muaj cov tub ntxhais tawv tawv thiab nitrided nto.
Khoom Qhia
Cov khoom siv
Cov khoom ntim
