Khoom Description

Peb Qhov Zoo

C70600 yog tsim los ntawm 90% tooj liab thiab 10% npib tsib xee, muab kev tiv thaiv rau seawater corrosion thiab biofouling, thaum muaj thermal conductivity zoo heev, ua rau nws haum rau siv nyob rau hauv tshav kub exchangers.
Peb B466 C70600 Tube tau kuaj cov tshuaj lom neeg muaj pes tsawg leeg thiab ntawv pov thawj kom ua tau raws li ASTM B466 / ASME SB466 cov qauv, thiab cov alloy muaj pes tsawg leeg tau lees paub los ntawm lub Hoobkas daim ntawv pov thawj.

Peb cov tubing yog tsim los ntawm kev ua kom txias - txheej txheem kos duab, kom ntseeg tau tias qhov ntev ntev. Txhua lub raj tau raug ntsuas nruj thiab tshuaj xyuas ua ntej xa khoom kom ntseeg tau tias nws tsim nyog rau cov khoom siv hluav taws xob los yog cov kav dej.
Kev tswj nruj nruj yog tswj hwm thoob plaws hauv cov txheej txheem tsim khoom, nrog rau kev sim nruj ntawm kev kos duab, ncaj, thiab kev ua haujlwm loj kom txo qis ovality, phab ntsa thickness variations, thiab txheej kab sib txawv.

Cov tubing muaj cov khoom siv vuam zoo heev thiab tuaj yeem siv vuam siv cov txheej txheem vuam feem ntau, xws li TIG thiab MIG vuam.
C70600 tooj liab-nickel alloy muaj qhov zoo tshaj plaws weldability thiab yooj yim ntawm formability. Cov tubing dhau qhov kev ntsuam xyuas flaring, tswj kev sib khi ruaj khov thaum tiv thaiv kev ntxhov siab. Cov tubing tuaj yeem txias - khoov, flared, lossis nthuav dav yam tsis muaj qhov tawg los yog wrinkling.

C70600 muaj zog corrosion kuj, tiv thaiv tawm tsam los ntawm seawater, brine, thiab lwm yam corrosive ib puag ncig, ua rau nws zoo tagnrho rau marine, offshore, thiab tshuaj siv.
Peb B466 C70600 Tube nthuav tawm cov kev tiv thaiv zoo rau seawater corrosion thiab biofouling, muab lub neej kev pab ntau tshaj 20-30 xyoo nyob rau hauv marine condensers thiab seawater systems, txo nqi txij nkawm.

Peb muab ntau yam kev xaiv ntim, nrog rau cov kaus mom yas, cov yeeb yaj kiab yas, cov hnab ntim khoom, thiab cov thawv ntoo, los tiv thaiv kev puas tsuaj los yog kis kab mob ntawm cov kav dej thaum thauj. Peb txhawb kev ya raws- pov thawj thiab xeb- pov thawj ntim, thiab txhua lub pob muaj cov lej taug qab.
Peb muaj ntau txoj kev thauj mus los, nrog rau kev thauj mus los hauv hiav txwv, huab cua, thiab av.

Kev lag luam marine: Seawater cooling systems, hluav taws-sib ntaus sib tua dej, thiab ballast dej systems.
Seawater desalination nroj tsuag: Siv nyob rau hauv brine rhaub thiab evaporator raj vim lawv tsis kam chloride corrosion.
Cov nroj tsuag muaj zog: Siv nyob rau hauv condensers thiab tshav kub exchangers rau kho dej hiav txwv los yog brackish txias dej.
Kev ua tshuaj lom neeg: Haum rau cov khoom siv hluav taws xob sib hloov thiab cov kav dej uas raug rau cov kua qaub tsis muaj zog.
Offshore roj thiab roj platforms: Haum rau cov dej hiav txwv txias, hluav taws kub - tawm tsam dej, thiab hydraulic systems.
HVAC thiab tub yees: Tsim nyog rau huab cua -txias thiab dej- cov cua sov hloov pauv uas xav tau kev tiv thaiv corrosion.

Element	Cu	Ni	Fe	Mn	Pb	Zn	Lwm tus
C70600	Tshuav	9.0 – 11.0	1.0 – 1.8	Tsawg dua los yog sib npaug rau 1.0	Tsawg dua los yog sib npaug li 0.05	Tsawg dua los yog sib npaug rau 1.0	Tsawg dua los yog sib npaug li 0.5

Qhov xwm txheej	Tensile zog (MPa)	Yield zog (MPa)	Elongation (%)	Hardness (HB)
Annealed (O)	Ntau dua lossis sib npaug li 275	Ntau dua lossis sib npaug rau 105	Ntau tshaj los yog sib npaug rau 30	Tsawg dua los yog sib npaug li 80
Lub teeb kos (H55)	Ntau dua lossis sib npaug rau 310	Ntau dua lossis sib npaug li 130	Ntau dua lossis sib npaug li 25	Tsawg dua los yog sib npaug li 100
Hard Drawn (H80)	Ntau dua lossis sib npaug rau 345	Ntau dua lossis sib npaug rau 165	Ntau dua lossis sib npaug li 15	Tsawg dua los yog sib npaug li 120

Alternative Qib	Yog vim li cas
C71500	Nws nthuav tawm zoo heev tiv thaiv corrosion, cuam tshuam, thiab siab -ceev seawater corrosion.
C71520	Ib qho kev txhim kho ntawm C71500, muab cov qauv zoo dua thiab weldability.
C68700	Aluminium tooj dag, kev lag luam lwm txoj hauv kev tsim nyog rau nruab nrab seawater corrosion tej yam kev mob.
