Khoom Description
Incoloy 800h 825 cev
Peb Qhov Zoo
- lus 825: Muaj kev tiv thaiv zoo heev rau kev ntxhov siab corrosion tawg los ntawm kev txo qis thiab oxidizing acids (sulfuric, phosphoric, thiab nitric acids), nrog rau cov tshuaj chlorides, txo cov yeeb nkab tsis ua hauj lwm, xau, thiab kev poob qis hauv kev sib hloov cua sov.
- Incoloy 800 H: Muab siab - kub lub zog thiab ruaj khov, tiv thaiv thermal cycling yam tsis muaj qhov cuam tshuam loj lossis tawg, ua rau nws zoo tagnrho rau siv hauv boiler feedwater heaters thiab petrochemical heat exchangers.
- Corrosion Resistance: Peb Incoloy 800H 825 yeeb nkab muaj kev tiv thaiv zoo heev rau pitting thiab crevice corrosion, ua rau nws zoo tagnrho rau marine thiab offshore tshav kub exchanger systems raug dej hiav txwv los yog dej brackish.
thaj chaw thov
- Condenser thiab cua sov exchangers: tshwj xeeb tshaj yog thaum tiv thaiv chloride kev nyuaj siab corrosion cracking yuav tsum tau.
- Petrochemical kev lag luam: Piping systems hauv hydrocarbon ua, ethylene ntau lawm, thiab cov khoom siv kho cua sov
- Nuclear fais fab kev lag luam: Chav generator piping thiab tshav kub exchanger piping
- Marine thiab offshore: Seawater-cooled heat exchangers thiab process piping
- Kev tsim hluav taws xob: Superheater raj, reheater raj, thiab boiler tubing
- Kev ua tshuaj lom neeg: Cov cuab yeej tuav sulfuric acid, phosphoric acid, thiab nitric acid
Tshuaj muaj pes tsawg leeg
| Element | Nickel | Chromium | Hlau | Molybdenum | Tooj | Titanium | Cov pa roj carbon | Alumninum | Manganese | Salicon |
| Incoloy 800 H | 30.0–35.0 | 19.0–23.0 | Tshuav | – | – | 0.15–0.60 | 0.05–0.10 | 0.15–0.60 | – | – |
| lus 825 | 38.0–46.0 | 19.5–23.5 | Tshuav | 2.5–3.5 | 1.5–3.0 | 0.6 max | 0.05 max | 0.2 max | 1.0 max | 0.5 max |
Mechanical Properties
| Khoom | Tensile zog (MPa) | Tawm Zog (0.2% Offset, MPa) | Elongation (%) |
| Incoloy 800 H | 450 (min) | 170 (min) | 30 (min) |
| lus 825 | 550 (min) | 220 (min) | 30 (min) |
Cov qhab nia xaiv tau
- Incoloy 800/800HT: Haum rau cov ntawv thov uas xav tau oxidation zoo sib xws thiab carburization tsis kam tab sis nrog qhov sib txawv ntawm qhov kub thiab txias me ntsis.
- Inconel 600/625: Zoo haum rau qhov kub thiab txias los yog ntau dua oxidizing ib puag ncig; Inconel 625 muaj cov dej hiav txwv zoo thiab cov kua qaub.
- Hastelloy C22 / C276: Haum rau kev txo qis lossis sib xyaw cov kua qaub ib puag ncig uas xav tau qhov siab tshaj plaws corrosion kuj.
- Stainless hlau 904L / 254 SMO: Ib qho kev xaiv zoo rau chloride- thaj chaw nplua nuj thaum nyiaj txiag yog qhov tseem ceeb, nws muaj zog tiv thaiv pitting corrosion.
Khoom Qhia
Cov khoom siv
Cov khoom ntim
