Khoom Description
Khoom Specifications
| Cov qauv | ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASME SA312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASTM A312 / ASME SA312) |
| Qib Steel | P XM-19 TP XM-10 TP XM-11 TP XM-15 TPXM-29 304 304L 304H 304LN 309S 309H 310S 316 316L 316LN 317 321 347 347H 348 904L, thiab lwm yam. |
| Cov qauv sib npaug | TS EN 10216-5, DIN 17456, JIS G3459, GOST 9941 |
| Sab nraud Diameter (OD) | 6mm-630mm, cuatomized |
| Phab ntsa Thickness (WT) | 0.5mm-55mm, cuatomized |
| Ntev | 6/12 m, luas |
| Kev kho saum npoo |
Pickled & Passivated |
| Txheej txheem ntau lawm | Kub Rolled / Cold Rolled / Cold Drawn |
| Qhov xwm txheej | Annealed & Pickled |
Piv rau cov pa roj carbon steel kav thiab welded stainless hlau kav, ASTM A312 seamless stainless hlau raj - tsim los ntawm cov txheej txheem xws li txias los yog txias dov - tshem tawm txoj kev pheej hmoo ntawm weld - seam to, yog li ua kom muaj kev nyab xeeb nyob rau hauv lub cev thaum tuav cov pa tawm los yog hydrogen{4}.
TORICH seamless raj yog tsim los ntawm cov qib stainless hlau xws li TP321H thiab TP316L, muab cov khoom daws teeb meem raws li kev ua haujlwm tshwj xeeb. TP316L zoo tiv thaiv corrosion los ntawm leej faj-cov kabmob refinery cov dej khib nyiab, dej hiav txwv cua txias, thiab cov roj acidic thiab roj ib puag ncig, thaum TP321H tuav lub zog zoo heev thiab ua rau muaj kev kub ntxhov ntawm qhov kub ntawm 550℃txog 800 degree.
Customized Services
- TORICH muaj tsis yog-txheej txheem sab nraud diameters thiab phab ntsa thicknesses, muaj peev xwm tsim tau rau specifications tshaj ASME B36.10/B36.19 kom tau raws li qhov ntev qhov yuav tsum tau rau tshwj xeeb daim ntawv thov xws li kub exchanger raj bundles thiab instrumentation tubing.
- Ntxiv rau cov txheej txheem kev daws teeb meem, cov txheej txheem kho cua sov tshwj xeeb- suav nrog kev ruaj khov, kev ntxhov siab- nyem annealing, thiab kev kho cryogenic- muaj.
- Customized kawg-cov kev pabcuam ua haujlwm tau muab, suav nrog V-bevel, U-bevel, thiab ob npaug V-bevel machining; NPT / BSPT tapered yeeb nkab threading; prefabricated flange vuam; thiab tube kawg flaring los yog swaging.
Tshuaj muaj pes tsawg leeg
| Qib | C | Cr | Ni | Mo | Mn | N | Si | P | S | Nb + Ta | Fe |
| TP XM-19 | Tsawg dua los yog sib npaug li 0.06 | 20.5 – 23.5 | 11.5 – 13.5 | 1.5 – 3.0 | 4.0 – 6.0 | 0.20 – 0.40 | Tsawg dua los yog sib npaug rau 1.0 | Tsawg dua los yog sib npaug li 0.04 | Tsawg dua lossis sib npaug li 0.03 | – | Tshuav |
| TP 309 H | 0.04 – 0.10 | 22.0 – 24.0 | 12.0 – 15.0 | – | Tsawg dua los yog sib npaug rau 2.0 | – | Tsawg dua los yog sib npaug li 1.5 | Tsawg dua lossis sib npaug li 0.045 | Tsawg dua lossis sib npaug li 0.03 | – | Tshuav |
| TIAB SA 348 | Tsawg dua lossis sib npaug li 0.08 | 17.0 – 20.0 | 9.0 – 13.0 | – | Tsawg dua los yog sib npaug rau 2.0 | – | Tsawg dua los yog sib npaug rau 1.0 | Tsawg dua lossis sib npaug li 0.045 | Tsawg dua lossis sib npaug li 0.03 | 10×C – 1.0 | Tshuav |
Mechanical Properties
| Khoom | Tensile zog (MPa) | Yield zog (MPa) | Elongation (%) | Hardness (HB) |
| TP XM-19 | Ntau dua lossis sib npaug rau 690 | Ntau dua lossis sib npaug rau 379 | Ntau dua lossis sib npaug li 35 | Tsawg dua los yog sib npaug li 100 |
| TP 309 H | Ntau dua lossis sib npaug li 515 | Ntau dua lossis sib npaug rau 205 | Ntau dua lossis sib npaug li 40 | Tsawg dua los yog sib npaug li 95 |
| TIAB SA 348 | Ntau dua lossis sib npaug li 515 | Ntau dua lossis sib npaug rau 205 | Ntau dua lossis sib npaug li 35 | Tsawg dua los yog sib npaug li 95 |
Cov qhab nia xaiv tau
- TP310H muaj cov qib siab ntawm chromium thiab npib tsib xee dua li TP309H, ua rau nws haum rau qhov kub siab heev - qhov kub thiab txias - xws li hydrocarbon refining furnace tubes thiab chav superheaters - txawm tias nws los ntawm tus nqi siab dua.
- Rau siab - siab, siab - chloride daim ntawv thov uas yuav tsum tau superior zog thiab zoo pitting corrosion kuj, 2205 duplex stainless hlau yog ib qho kev xaiv tsim nyog.
- TP347/TP347H yog tus nqi ntau dua- zoo dua TP348 thiab nquag siv hauv kev lag luam petrochemical rau siab -kub, hydrogen- nplua nuj kev pabcuam thiab cov ntawv thov uas yuav tsum tau ua haujlwm rau polythionic acid kev nyuaj siab corrosion cracking.
thaj chaw thov
- Crude Distillation Unit (CDU/VDU): Atmospheric and vacuum tower overhead kab, sab -kos piping, thiab furnace radiant tubes.
- Kua Catalytic Cracking (FCC) & Hydrocracking: Siab -kub catalyst hloov kab, lub ntsiab fractionator kub exchanger raj bundles, thiab reactor hydrocarbon vapor kab.
- Hydrodesulfurization/Hydrotreating (HDS/HDT): High -siab stainless steel raj bundles rau hydrogen kev pab cuam, reactor inlet / qhov hluav taws xob piping, thiab qaub dej neutralization kab.
- Ncua Coking & Visbreaking: Coke nruas pub kab, quench roj kav dej, thiab lub cub tawg convection hlab; yuav tsum tau ua hauj lwm rau siab -kub creep thiab sulfidation.
- Sulfur Recovery & Tail Gas Treatment (SRU/TGTU): Cov txheej txheem roj reheaters thiab acid gas heat-traced kab; yuav tsum tau tiv thaiv sulfide kev nyuaj siab corrosion cracking.
- Liquefied Natural Gas (LNG) & Gas Fractionation: Kev nyab xeeb valve bypasses rau cryogenic liquefaction kab thiab boil-tawm roj (BOG) tuav kab.
Khoom Qhia
Cov khoom siv kuaj
Khoom siv Hoobkas
Cov khoom siv Pickling
Cov khoom ntim
FAQ
Q: Dhau li ntawm tus qauv 6-meter ntev, koj puas tuaj yeem muab cov kav dej ntev dua kom txo tau cov pob qij txha?
A: A: Yog. Peb muaj peev xwm muab ib leeg, seamless kav ntawm 9 meters, 12 meters, thiab txawm 18 meters, tshwj xeeb tshaj yog haum rau tshav kub exchanger raj bundles thiab txheej txheem piping ntawm cov yeeb nkab racks.
Q: ASTM A312 seamless stainless hlau raj puas tuaj yeem siv rau hauv cov roj acidic thiab roj ib puag ncig uas muaj hydrogen sulfide (H₂S)?
A: Yog. TP316L stainless hlau yog tsim rau me me mus rau nruab nrab qaub kev pab cuam. Rau qhov hnyav H₂S ib puag ncig, xaiv cov khoom siv yuav tsum ua raws NACE MR0175 / ISO 15156 cov cai, nrog Duplex 2205 lossis npib tsib xee alloys pom zoo kom muaj kev tiv thaiv corrosion ntau dua.
Q: Qhov kev pabcuam siab tshaj plaws ntawm ASTM A312 stainless hlau yeeb nkab yog dab tsi?
A: Nws nyob ntawm cov khoom siv tshwj xeeb qib thiab cov txheej txheem tsis ua haujlwm. Los ntawm qhov kev xav ntawm oxidation tsis kam, qhov kev pabcuam txuas ntxiv rau TP304/316 yog kwv yees li 870 degree, thaum TP310S tuaj yeem ncav cuag 1050 degree.
