Khoom Description
Peb Qhov Zoo
1. Zoo heev Corrosion Resistance
- Stainless hlau ERW yeeb nkab yog ua los ntawm siab- zoo stainless hlau, muab zoo heev corrosion kuj thiab polished nto tiav. 316- qib stainless hlau muaj 2-3% molybdenum, ua rau nws haum rau marine thiab tshuaj ib puag ncig.
- Cov ntaub ntawv nyoos tau dhau los kuaj cov tshuaj lom neeg muaj pes tsawg leeg kom ua tau raws li ASTM A358 tus qauv, thiab kev kuaj kev sib xyaw ua ke tau ua kom ntseeg tau tias cov kav dej tuaj yeem siv rau lub sijhawm ntev hauv thaj chaw corrosive.
2. Vuam zoo
- Peb cov kav dej yog tsim los siv hluav taws xob tiv thaiv vuam (ERW) thev naus laus zis. Cov hlau tsis muaj steel yog txias- ua rau hauv cov duab cylindrical thiab tom qab ntawd longitudinally taub qab -welded siv cov vuam tsis kam. Tsis muaj cov hlau muab tub lim ntxiv, uas ua rau muaj qhov sib txuas zoo sib xws thiab cov qauv hlau tsis sib xws.
- Cov kav dej tau dhau los tom qab-weld kev kho mob, suav nrog kev kho cua sov, sib tsoo, thiab polishing, kom ntseeg tau qhov seamless thiab corrosion- tiv taus nto.
3. Kev kho deg
- Stainless hlau ERW yeeb nkab muaj qhov polished nto, ua rau nws zoo nkauj thiab haum rau kev lag luam xws li kho vaj tse vaj tse thiab tshuaj.
- Peb muab cov qib polishing sib txawv, suav nrog 180 #, 240 #, 320#, lossis iav polishing. Rau kev siv huv huv, peb muab electropolishing.
4. Kev Pabcuam Customization
- TORICH muab cov kev pabcuam sizing customized, ntau yam kev kho mob saum npoo, thiab kev ua tiav cov kev xaiv xws li beveling, tiaj kawg, thiab threading kom tau raws li cov kev xav tau ntawm ntau yam kev lag luam.
- Peb kuj tuaj yeem ua dabtsi yog khoov, txiav, drilling, thiab grooving raws li qhov project drawings. Cov ntaub ntawv stainless hlau tsim nyog tuaj yeem muab tau raws li cov neeg siv khoom thov.
thaj chaw thov
- Chemical thiab petrochemical kev lag luam: Siv rau thauj cov kua qaub thiab alkalis, corrosive kua, thiab reactors thiab tshav kub exchangers.
- Pharmaceutical thiab biotechnology: Siv nyob rau hauv cov kav dej huv huv, cov khoom siv tshuaj ntau lawm, thiab kev thauj cov kua dej tsis muaj menyuam.
- Kev siv architectural thiab kho kom zoo nkauj: Siv nyob rau hauv tes tuav, railings, sab nrauv phab ntsa, thiab structural piping nyob rau hauv niaj hnub vaj tse.
- Roj thiab roj kev lag luam: Siv rau offshore thiab onshore dej tuav yuav tsum muaj corrosion kuj.
- Kev kho dej thiab desalination nroj tsuag: Siv nyob rau hauv seawater thiab brine thauj systems, tshwj xeeb tshaj yog 316/316L steel kav.
- Automotive: Siv nyob rau hauv cov kav dej, luas, thiab roj kab.
Tshuaj muaj pes tsawg leeg
| Element | C (%) | Mn (%) | Si (%) | P (%) max | S (%) max | Cr (%) | Tsis muaj (%) | Mo (%) |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.08 max | max 2.00 Nws | max 1.00 Nws | 0.045 | 0.030 | 18.0–20.0 | 8.0–11.0 | - |
| 316 | 0.08 max | max 2.00 Nws | max 1.00 Nws | 0.045 | 0.030 | 16.0–18.0 | 10.0–14.0 | 2.0–3.0 |
| 321 | 0.08 max | max 2.00 Nws | max 1.00 Nws | 0.045 | 0.030 | 17.0–19.0 | 9.0–12.0 | - |
| 347 | 0.08 max | max 2.00 Nws | max 1.00 Nws | 0.045 | 0.030 | 17.0–19.0 | 9.0–13.0 | - |
Mechanical Properties
| Khoom | Tensile zog (MPa) | Yield zog 0.2% (MPa) | Elongation (%) | Hardness (HB) |
| 304 | 515 nqi | 205 feeb | 40 | 201 max |
| 316 | 515 nqi | 205 feeb | 40 | 217 max |
| 321 | 515 nqi | 205 feeb | 40 | 217 max |
| 347 | 515 nqi | 205 feeb | 40 | 217 max |
Cov qhab nia xaiv tau
| Alternative Qib | Yog vim li cas |
| TP 904 L | High nickel thiab molybdenum cov ntsiab lus muab kev tiv thaiv zoo heev rau acid thiab seawater corrosion. |
| Duplex 2205 (UNS S32205) | Lub dual-txheej txheej microstructure txhim khu lub zog thiab tiv thaiv kev ntxhov siab corrosion tawg. |
| alloy 825 | Zoo heev corrosion kuj nyob rau hauv acidic thiab chloride -muaj ib puag ncig. |
Khoom Qhia
Cov khoom siv kuaj
Khoom siv Hoobkas
Cov khoom siv Pickling
Cov khoom ntim
FAQ
Q: Yuav ua li cas txhim khu kev qha cov welds ntawm ERW polished raj?
A: Peb cov kav dej yog tsim los siv cov khoom siv hluav taws xob siab tshaj vuam (ERW) tshuab. Cov welds yog tag nrho fused, kev ntxhov siab -relived, thiab polished. Peb kuj tseem ua qhov tsis yog -kev kuaj kev puas tsuaj (UT/RT) thiab kuaj hydrostatic los xyuas qhov zoo ntawm cov vuam.
Q: Kev kho deg puas tuaj yeem kho tau?
A: Yog. Peb muab ntau yam polished nto tiav kom tau raws li qhov yuav tsum tau ua, suav nrog 180 #, 240 #, 320 #, thiab daim iav polishing. Tsis tas li ntawd, passivation, pickling, lossis electrochemical polishing kev kho mob tuaj yeem siv los txhim kho corrosion kuj thiab cov qauv kev nyiam huv rau cov zaub mov, tshuaj, lossis tshuaj lom neeg kev lag luam.
Q: Koj puas muab cov ntaub ntawv zoo thiab cov ntaub ntawv xeem dab tsi?
A: Peb muab cov ntaub ntawv pov thawj hauv Hoobkas (EN 10204 3.1 / 3.2), hydrostatic thiab flattening/bending test reports, intergranular corrosion (ASTM A262) test reports, ultrasonic test reports, etc.
