Khoom Description
Peb Qhov Zoo
- Corrosion Resistance: Cov ntsiab lus siab nickel nyob rau hauv SUS315J1TP txhim khu kev tiv thaiv rau acidic thiab alkaline xov xwm, ncua lub neej ntawm cov yeeb nkab.
- Mechanical Properties: Peb SUS304TP stainless hlau capillary raj nthuav tawm zoo heev elongation, ua kom yooj yim sib sau, khoov, thiab coiling yam tsis muaj cracking. Nws tuaj yeem siv rau hauv siab -siab, vibration- cov tshuab ua haujlwm.
- Siab -Kev Ua Haujlwm Siab: Piv rau tooj liab capillary tubing, peb SUS304TP Stainless Steel Capillary Tube muaj zog dua thiab siab ua haujlwm, ua rau nws haum rau siab - cov kab ntsuas ntsuas, hydraulic, thiab pneumatic tswj tshuab.
thaj chaw thov
- Instrumentation thiab Control Systems: Cov ntsuas ntsuas siab, qhov sib txawv ntawm qhov sib txawv, thiab ntsuas ntsuas kub.
- Kev Kho Mob thiab Pharmaceutical Industries: Hypodermic koob, cov cuab yeej phais thiab catheters, cov khoom siv roj kho mob, thiab cov khoom siv phais mob tsawg kawg nkaus.
- Electronics thiab Semiconductor Manufacturing: Cov tshuab cua txias rau cov cuab yeej hluav taws xob precision, siab -cov kav dej huv huv rau kev tsim khoom semiconductor.
- Automotive thiab Aerospace: Precision roj kab, nres kab, thiab hydraulic tswj kab, nrog rau cov hlab capillary hauv tub yees thiab cua txias.
- Laboratories: Chromatography thiab analytical instrument tubing, lub tshuab nqus tsev, thiab cryogenic pipelines.
Tshuaj muaj pes tsawg leeg
| Element | C (max) | Si (max) | Mn (max) | P (max) | S (max) | Cr | Ni | Mo |
| SUS304TP | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0–20.0 | 8.0–10.5 | - |
| SUS315J1TP | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 17.0–19.0 | 12.0–15.0 | - |
| SUS 316 LTP | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0–18.0 | 10.0–14.0 | 2.0–3.0 |
Mechanical Properties
| Khoom | Tensile zog (MPa) | Yield zog (MPa) | Elongation (%) | Hardness (HB) |
| SUS304TP | Ntau dua lossis sib npaug li 520 | Ntau dua lossis sib npaug rau 205 | Ntau dua lossis sib npaug li 35 | Tsawg dua los yog sib npaug rau 192 |
| SUS315J1TP | Ntau dua lossis sib npaug li 520 | Ntau dua lossis sib npaug rau 205 | Ntau dua lossis sib npaug li 35 | Tsawg dua los yog sib npaug rau 192 |
| SUS 316 LTP | Ntau dua lossis sib npaug li 520 | Ntau dua lossis sib npaug rau 205 | Ntau dua lossis sib npaug li 35 | Tsawg dua los yog sib npaug rau 192 |
Cov qhab nia xaiv tau
- Rau cov ntawv thov uas yuav tsum tau ua kom sov siab dua,SUS 310 Stuaj yeem siv ua lwm yam.
- Yog tias yuav tsum tau ua kom muaj zog tiv thaiv chloride kev nyuaj siab corrosion cracking,SUS 317Llos yog duplex stainless hlau (xws li SUS329J4L, S32205) raug pom zoo.
- Yog tias qhov zoo tshaj plaws siab -kub creep zog yuav tsum tau,SUS 347 Htuaj yeem txiav txim siab.
- Yog xav tau lub zog siab dua thiab txhim kho pitting corrosion kuj, super-austenitic stainless hlau (254 SIB, N08904) tuaj yeem siv ua lwm yam.
Khoom Qhia
Cov khoom siv
Cov khoom ntim
