Khoom Description
Peb Qhov Zoo
1. Siab zog
- Peb 410 Stainless Hlau Yeeb Nkab yog tsim los ntawm hwm martensitic stainless hlau, muab lub zog tensile zoo, yield zog, thiab hardness. Haum rau cov ntawv thov raug rau cov neeg kho tshuab kev ntxhov siab, kev hloov pauv siab, thiab xav tau cov qauv tsim.
- TORICH cov kav dej tau dhau los kuaj cov khoom siv raw, suav nrog kev tshuaj xyuas tshuaj muaj pes tsawg leeg thiab kev ntsuas cov cuab yeej siv tshuab, kom ntseeg tau tias ua raws li cov qauv thiab cov qauv tshwj xeeb.
2. High Wear Resistance
- Peb cov kav dej tau ua kom muaj zog kom ua tiav siab tawv, ua kom pom kev hnav zoo heev, tiv thaiv corrosion, thiab tsis kam rau cov khoom siv hlau, ua rau lawv haum rau cov tshuab, hydraulic systems, thiab petrochemical cov cuab yeej xav tau kev pab lub neej ntev.
- Tsis tas li ntawd, peb cov kav dej tau txais kev kho cua sov los txhim kho toughness, txo qhov kev pheej hmoo ntawm kev tawg thaum tswj siab hardness.
3. Siab Dimensional raug
- Peb cov kav dej yog qhov txias txias-kos, txiav ncaj, thiab ua raws li kev tswj hwm nruj, ua kom cov phab ntsa tuab tuab thiab du sab hauv, ua rau lawv haum rau cov tshuab thiab hydraulic uas xav tau qhov ntev.
- TORICH cov kav dej tau txais kev ntsuas qhov ntev, nrog cov phab ntsa tuab ntsuas siv lub ntsuas ntsuas ultrasonic kom ntseeg tau tias cov tuab tuab ntawm tag nrho cov yeeb nkab ntev, tshem tawm cov ntsiab lus tsis muaj zog thiab ua kom ruaj khov siab ua haujlwm.
4. Secondary Machining Performance
- Peb 410 stainless hlau kav muaj kev ua haujlwm zoo dua piv rau ntau lwm qib ntawm cov hlau tsis muaj steel, ua rau kev ua haujlwm theem nrab xws li xov, txiav, drilling, thiab vuam.
- TORICH muaj kev cai ntau thiab tsawg thiab tuab- phab ntsa configurations (ntxiv-thick and extra-tick wall options available), as well as deg treatments such as pickling, passivation, and polishing.
thaj chaw thov
- Mechanical Engineering: Shafts, bushings, tes tsho, thiab precision machined qhov chaw
- Petrochemicals: High-cov kav dej siab, cov khoom siv kho tshuab, cov kav dej ua ke
- Automotive: Cov pa hluav taws xob, cov khoom siv txhawb nqa, siab - qhov kub thiab txias
- Muaj Machinery: Pump shafts, valve Cheebtsam, hnav-cov khoom tiv taus
- Lub zog tiam: Boiler Cheebtsam, chav turbines, cua sov-cov qauv tiv thaiv
- Roj & Roj: Downhole cov cuab yeej, siab -cov kav dej muaj zog
Tshuaj muaj pes tsawg leeg
| Element | C | Mn | Si | P (max) | S (max) | Cr |
|---|---|---|---|---|---|---|
| 410 | 0.08–0.15 | Tsawg dua lossis sib npaug li 1.00 | Tsawg dua lossis sib npaug li 1.00 | 0.040 | 0.030 | 11.5–13.5 |
Mechanical Properties
| Khoom | Tensile zog (MPa) | Yield zog (MPa) | Elongation (%) | Hardness (HB) |
| 410 (Nyob rau hauv) | Ntau dua lossis sib npaug li 450 | Ntau dua lossis sib npaug li 275 | Ntau tshaj los yog sib npaug rau 20 | Tsawg dua lossis sib npaug li 183 |
| 410 (Hardened & Tempered) | 650–850 | 450–650 | 15–20 | 200–300 |
Cov qhab nia xaiv tau
| Alternative Qib | Yog vim li cas |
| 420 | Cov ntsiab lus carbon ntau dua, ua rau muaj zog dua thiab hnav tsis kam. |
| 416 | Ib qho yooj yim rau machinable, haum rau cov khoom uas tsis tshua xav tau machining. |
| 430 | Zoo dua corrosion kuj, haum rau cov ntawv thov nrog cov khoom siv qis dua. |
| EN 1.4006/X12Cr13 | European tus qauv, sib npaug rau AISI 410, tsim nyog rau kev siv tshuab zoo sib xws. |
Khoom Qhia
Cov khoom siv kuaj
Eddy Tam sim no Flaw Detector
Hydraulic Universal Test tshuab
Intergranular Corrosion Tester
Khoom siv Hoobkas
Cov khoom siv Pickling
Cov khoom siv polishing
Cov khoom siv kos duab txias
Cov khoom ntim
