Khoom Description
Khoom Specifications
| Cov qauv | ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASME SA312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASME SA312 / ASTM A312 / ASTM A312 / ASTM A312 / ASME SA312) |
| Qib Steel | TP316L (UNS S31603) |
| Cov qauv sib npaug | EN 10216-5 1.4404 / 1.4401, JIS G3459 SUS316LTP, GOST 03Ch17N14M3 |
| Sab nraud Diameter (OD) | 5 hli - 630 hli, customized |
| Phab ntsa Thickness (WT) | 0.5 hli - 55 hli, customized |
| Ntev | 6/12 m, lossis customized |
| Kev kho saum npoo | Pickling thiab passivation |
| Txheej txheem ntau lawm | Kub Rolled, Txias Rolled, Txias Drawn |
| Qhov xwm txheej | Annealed |
ASTM A312 TP316L yog ib qho ntxiv -tsis tshua muaj carbon austenitic stainless hlau; tshuaj annealing zoo tiv thaiv chromium carbide nag lossis daus thiab tshem tawm cov kev pheej hmoo ntawm intergranular corrosion tom qab vuam los yog kub ua hauj lwm, tso cai rau siv ncaj qha yam tsis muaj post-weld kho cua sov.
Tsim los siv cov txheej txheem seamless nrog tuab - phab ntsa tsim, Sa 312 316l Thick Wall Seamless Stainless Steel Tube withstands kev khiav hauj lwm siab tshaj 42 MPa, ua tshwj xeeb tshaj yog haum rau siab - siab zoo tswj kab, tshuaj txhaj tshuaj, thiab instrumentation tubing.
Piv rau 304/304L qib, 316L muaj kev pab cuam lub neej ntev dua peb zaug nyob rau hauv ib puag ncig raug cov ntsev tsuag, dej hiav txwv txaws, thiab kua qaub crude roj, nrog rau kev khiav hauj lwm kub ntawm -196℃mus rau 450 degree.
Customized Services
- TORICH muaj kev kho kom haum rau cov uas tsis yog-txoj kab uas hla sab nraud thiab nce phab ntsa thicknesses, muaj peev xwm ua tau ultra-tuab- phab ntsa piping mus txog 80mm.
- Txhawm rau tiv taus qhov siab -salinity, corrosive ib puag ncig ntawm offshore roj thiab roj platforms, peb muab cov kev kho mob saum npoo xws li txhim kho pickling thiab passivation, daim iav polishing, thiab matte sandblasting rau corrosion kuj.
- Peb muab cov kev pabcuam siab tshaj plaws, suav nrog cov yeeb nkab kawg beveling, threading, flange welding, swaging, thiab flaring.
- Customized ntim cov kev xaiv muaj, suav nrog cov roj los tiv thaiv- xeb, cov ntaub qhwv tsis muaj dej, cov ntoo pallets, thiab tiv thaiv- cov thawv xeb.
Tshuaj muaj pes tsawg leeg
| Element | Cov pa roj carbon | Manganese | Silicon | Phosphorus | Sulfur | Chromium | Nickel | Molybdenum | Nitrogen |
| Cov ntsiab lus (%) | Tsawg dua lossis sib npaug li 0.035 | Tsawg dua lossis sib npaug li 2.00 | Tsawg dua lossis sib npaug li 0.75 | Tsawg dua lossis sib npaug li 0.045 | Tsawg dua lossis sib npaug li 0.030 | 16.0 – 18.0 | 10.0 – 14.0 | 2.0 – 3.0 | Tsawg dua lossis sib npaug li 0.10 |
Mechanical Properties
| Khoom | Tensile zog | Yield zog | Elongation | Hardness |
| Tus nqi | Ntau dua lossis sib npaug li 485 MPa | Ntau dua lossis sib npaug li 170 MPa | Ntau dua lossis sib npaug li 40% | Tsawg dua lossis sib npaug li 217 HB |
Cov qhab nia xaiv tau
- Rau cov cua kub exchanger raj thiab siab -kub refinery kab, TP316Ti yog ib qho kev xaiv; thaum me ntsis kim dua 316L, nws muaj kev ruaj ntseg ntau dua nyob rau hauv welded, siab -kub tshuab, txawm hais tias nws muaj qis tsis kam rau seawater corrosion.
- Duplex stainless hlau 2205 muaj superior pitting tsis kam thiab siab zog tawm los piv rau 316L; Txawm li cas los xij, nws raug nqi ntau dua 40% ntau dua thiab nthuav tawm tsis zoo qis -kub toughness thiab tsis kam rau qis - kub corrosion.
- Alloy 625 muab kev tiv thaiv zoo tshaj rau cov tshuaj chloride- ion corrosion thiab zoo heev - kub stability piv rau 316L, ua rau nws haum rau siab - kub, corrosive txheej txheem kav, txawm hais tias nws cov nqi yog ntau tshaj 8-10 npaug ntawm 316L.
daim ntawv thov
SA 312 TP316L hnyav-phab ntsa seamless stainless hlau kav yog dav siv nyob rau hauv sab sauv thiab downstream systems nyob rau hauv cov roj thiab roj kev lag luam.
- Offshore roj thiab roj ntau lawm platforms: Seawater cooling systems, firewater piping systems, and produce water treatment piping systems.
- Subsea thiab offshore auxiliary systems: Cov khoom tiv thaiv rau subsea tswj kab thiab auxiliary piping systems rau tshuaj txhaj tshuaj.
- Roj refining txheej txheem chav tsev: Distillation chav piping thiab txias dej ncig systems.
- Gas processing and compression stations: CO2 thiab ntub gas processing systems and fuel gas distribution systems.
Khoom Qhia
Cov khoom siv kuaj
Khoom siv Hoobkas
Cov khoom siv Pickling
Cov khoom ntim
FAQ
Q: Puas yog 316L yeeb nkab xav tau kev kho cua sov tom qab vuam?
A: Tsis yog. 316L muaj cov ntsiab lus carbon tsawg dua los yog sib npaug li 0.03%, tshem tawm qhov kev pheej hmoo ntawm kev xeb ntawm intergranular. Tshaj tawm -weld solution annealing yog qhov tsis tsim nyog, ua kom yooj yim rau ntawm - cov txheej txheem roj thiab roj thiab txo cov nqi.
Q: 316L stainless hlau puas tuaj yeem siv rau hauv qhov chaw acidic uas muaj hydrogen sulfide?
A: Yog lawm, hauv kev pabcuam me me thaum ua raws li NACE MR0175 cov cai.
Q: Cov kev kho deg twg yog muaj?
A: Cov kav dej yog muab los ntawm cov khoom noj khoom haus thiab cov khoom noj khoom haus (dawb nyiaj -dawb). Bright annealing (BA qib), mechanical polishing rau 400 # lossis 600 # tiav, lossis ib ntus los tiv thaiv- xeb txheej raws li xav tau. Rau thaj chaw welded, ua ntej -grooved beveling tiv thaiv kuj tau teev tseg.
